Release Notes

Document image


2.1

Release Date: 7th November 2024

We're pleased to announce the release of CinCraft Scenario 2.1

New Features

Manual Lens Calibration - Users are able to create their own lenses in the equipment manager and calibrate them so that they are ready to be used in a tracking configuration

Manual CamBar Offset - Users are able to manually adjust the CamBar offset found in the "CamBar Offset" panel of the dashboard. This allows users to achieve a cambar offset value when the assistant is not possible/desired

Clipname in Wrangler - In the wrangler recording interface a new "clip name" field is available. When using supported cameras (ARRI and SONY) the field should be auto-populated. On unsupported cameras the field is user editable to allow for the input of a clip name manually

Improvements

External Encoder Homing Reminder - When using external encoders only and the user changes the used calibration in the settings panel of the dashboard, a small reminder will appear to remind them that the external encoders will need rehoming

Lens Finetuning and Manual Calibration merged - The lens finetuning workflow introduced in 2.0 has now been merged into the manual calibration workflow. This allows users to make more indepth changes to the included lens templates

CamBar Offset during calibration improvements - The process for calculating the CamBar offset during lens calibration has been refined. The user is provided with more guidance and is offered a manual method

Link Update Status - When connecting a Link with an older version of software on it, an update message will be displayed in the UI to the user so that they are aware of the update process happening. This message will only appear when an out of date link is connected and will not appear when the Link is connected during the Scenario update process

Warning when entering Marker place/learn steps - A user is now warned that after completing the Reflective Marker setup, that if they try and re-enter the "Place" or "Learn" stages of the marker setup then they will need to relearn all existing markers

Low Density Pointcloud option - The user can now select a "low" option for the pointcloud density.

Default Tracking Smoothing applied - When creating a tracking configuration a default tracking smoothing of "low" is enabled by default

Bug Fixes

  • Fixed discrepancy between the frontend and backend renderers
  • Fixed calibration retargeting when moving lenses between cameras
  • Fixed manual and template lenses not being copied when cloning a camera
  • View inverted when using Ncam Mk2 Camera Bar
  • Incorrect zoom value displayed
  • Wrong initial offset values used for CamBar offset in lens calibration
  • Encoder mapping not saved if values left blank
  • UI blocking nodal input value
  • Centre shift line not visible during centre shift calibration
  • Smoother zoom when using /i zoom lenses and /i encoder cable
  • Fixed Canon and Fujinon encoders not being marked as "normalised"
